Single Sided Cantilever Rack

item No: SSCR-007
Dimensions: 82" width x 61" depth x 120" height
Arm Length: 48 inches
Number of Arms: 8
Arm Capacity: 1,000 lbs per arm
Total Unit Capacity: 9,730 lbs
Material: 12-gauge steel

ADD TO FAVORITES INQUIRY NOW

Collections: Warehouse Racking System > Cantilever Pallet Racking

DESCRIPTION

Packaging & Shipping

FAQ

A single-sided cantilever rack is a specialized storage system designed for holding long, bulky, and irregularly shaped items such as lumber, pipes, steel bars, and furniture. It is a widely used solution in warehouses, distribution centers, and manufacturing facilities where efficient space utilization and easy access to materials are essential.

Structural Design

A single-sided cantilever rack consists of several key components, including a vertical column, horizontal arms, a base, and bracing. The vertical column provides the main support structure, while the arms extend outward to hold the stored materials. The base is designed to ensure stability, particularly when dealing with heavy loads. Bracing is often added between columns to enhance structural integrity. Unlike double-sided racks, which allow access from both sides, single-sided cantilever racks are designed to be placed against walls or other fixed structures.

Functionality and Load Capacity

The primary function of a single-sided cantilever rack is to store long materials in an organized manner, making retrieval quick and efficient. The absence of front columns provides unobstructed access, allowing forklifts and other material handling equipment to easily load and unload items. Load capacities vary based on the design, materials, and dimensions, with some heavy-duty models capable of supporting thousands of pounds per arm.

Advantages

Efficient Space Utilization – Since single-sided cantilever racks can be positioned against walls, they maximize vertical storage while leaving the central warehouse space open for other operations.
Flexible Storage – Adjustable arms allow customization based on the length and size of the stored materials.
Easy Access – Unlike traditional pallet racking, cantilever racks eliminate front columns, making it easier to store and retrieve long and bulky items.
Durability – Typically made from high-strength steel, these racks are built to withstand heavy loads and harsh warehouse environments.

Common Applications

Single-sided cantilever racks are widely used in industries that require the storage of elongated materials. Common applications include:
Lumberyards – For storing wooden planks, plywood, and beams.
Metal Fabrication Shops – Used to store steel pipes, bars, and sheets.
Furniture Warehouses – Ideal for holding sofas, mattresses, and other large furniture pieces.
Construction Material Storage – Suitable for keeping plastic tubing, PVC pipes, and drywall sheets.
Installation and Maintenance
Proper installation is crucial for safety and performance. The base must be securely anchored to the warehouse floor to prevent tipping. Regular maintenance includes checking for structural integrity, ensuring bolts and fasteners are tight, and inspecting for any signs of damage or overloading.

Conclusion

A single-sided cantilever rack is an efficient and practical storage solution for long and bulky materials. Its open-front design, adjustable arms, and strong construction make it a valuable asset in warehouses and industrial settings. By optimizing space and improving accessibility, these racks enhance warehouse operations and streamline inventory management.

Do you offer samples available?

Yes, samples are available. Sample lead time 3-5days generally.
Do you offer custom design?

Custom design is surely available. we have very rich experience in customizing shelves.
What is the term of payment?

Regularly, 30percentTT in advance,70percent against the copy of B/L.
What is your delivery time?

Usually: 1*20' GP container, around 15 days; 1*40'GP container, around 20days; For some urgent orders,will adjust as your requirement accordingly.
Are you manufacturer or trading company?

We are manufacturer. Our factory has been specializing in warehouse storage equipments for years. We warmly welcome you to visit our factory at anytime.
